Body
: Alu Body/RAL7016
Optic Cover
: PMMA Asymmetric Lens M2 M3 Road Class
Led Driver
: Osram-Tridonic-Philips
Led Chip
: Samsung, Osram
Input Voltage
: 220-240V/AC 50-60Hz
Temperature Range
: -10°C~+40°C
CRI
: CRI > 80
IP Class
: IP66
Options
: Color Temperature :
2700K/3000K/4000K/6500K
DALI
Application Areas
Garden • Facade • Roadway • Street • Highway
Designed for use in environments that demand both strong light and extended lifespan.
Item Code
Power (W)
Luminaire Lumen (lm)
Color Temperature (K)
Efficiency (lm/W)
Dimension (LxWxH)
Qty/Carton
Carton Size (LxWxH)
G.W/Carton
LYC10.065
60W
8.125
1800/3000/4000/6500
130lm/W
550x263x65mm
1
600x300x100mm
5 kg
LYC10.085
85W
11.900
140lm/W
LYC10.105
105W
14.700
*3N Company has the right to make any changes it deems necessary without prior notice.
*Technical data has a tolerance of ± 10%.
